Specific parameters and core advantages of Kawasaki K-series 20kg-1725 robotic arm

The specific parameters of the model "20kg-1725 arm" are not explicitly mentioned in the Kawasaki K-series robotic arm. However, based on the K-series product line and user requirements (load of 20kg, arm length of approximately 1725mm), the following are the core advantages and related technical features of the Kawasaki K-series robotic arm:

1、 Core advantages

Explosion proof and safety design

The K series is developed specifically for spray painting scenarios, with an explosion-proof rating of Expid Ⅱ BT4/Exib Ⅱ BT4, suitable for flammable and explosive environments such as spray painting workshops. Some models (such as KF121) adopt a dual protection mechanism of "intrinsic safety explosion-proof" and "internal pressure explosion-proof" to ensure high safety.

Explosion proof electrical control cabinet and dust-proof and waterproof design (IP65/IP67), suitable for harsh industrial environments.

Hollow wrist and built-in tube

Standard hollow wrist arm, with an optional inner diameter of 40mm or 70mm, allowing for internal installation of hoses to reduce external pipeline pollution during spraying and lower the rate of paint surface defects.

The integrated pipeline system maximizes dust and dirt prevention, improving the consistency of spraying quality.

Programming flexibility and efficient control

Support box step programming (automatic path generation) and AS language programming (logical complex tasks) to reduce teaching time and improve programming efficiency.

The control panel provides a graphical interface that integrates peripheral interfaces such as robot walking units and workpiece conveying units, simplifying system construction.

Load and motion performance

The load range covers 5kg to 30kg (such as the KG264 model with 20kg for the wrist and 30kg for the arm), with 6-axis freedom of movement and a repeat positioning accuracy of ± 0.5mm, meeting the requirements of high-precision spraying.

Some models (such as KJ314) have been expanded to a 7-axis design, enhancing the coverage of complex spray areas, with a maximum horizontal range of up to 3100mm.

Modularization and rapid deployment

The complete set of units is designed to be compact and can be quickly installed in limited spaces, and immediately put into spraying operation, reducing production line downtime.

Servo peripherals (such as positioning products) support flexible expansion and adapt to different spraying process requirements.

2、 Typical application scenarios

Automotive manufacturing: body spraying (such as KF121 used in automotive production lines), chassis interior and exterior spraying (KG264 adapted to heavy-duty requirements).

3C Electronics: Light load models (such as KF121) are suitable for precision component spraying.

Film and television special effects: Long arm display models (such as RS013N) are used for dynamic painting in film shooting.

3、 Market and Service

Localization support: Kawasaki has a professional team in China that provides full process services from planning to equipment start-up, and promises a 30 minute phone response and 24-hour on-site maintenance.

Cost effectiveness: Compared to European and American brands such as ABB and FANUC, the K series has a moderate price and lower maintenance costs

4、 Example of Technical Parameters (KF192)

Parameter: numerical value

Maximum coverage range: 1725mm

Load capacity: arm 20kg

Repetitive positioning accuracy: ± 0.5mm

Protection level: IP65

Explosion proof grade: Expid Ⅱ BT4/Exib Ⅱ BT4

Installation method: Ground/Wall mounted
